2024 Mercedes-Benz Sprinter Cargo Van
$49,900 - $74,200Starting MSRP
Jet Black
Model Highlights
Transmission
Automatic w/OD
Body Type
Van
Seatings
2 Seats
Build Your Own 2024 Mercedes-Benz Sprinter Cargo Van
Looking for alternatives to the Mercedes-Benz Sprinter Cargo Van?
Start Comparing NowColors
Exterior
Jet Black
Obsidian Black Metallic
Black Blue
Brilliant Blue
Cavansite Blue Metallic
Steel Blue
Vanda Blue
Blue Grey
Graphite Grey
Pebble Grey
Selenite Grey Metallic
Silver Grey
Stone Grey
Tenorite Grey Metallic
Aqua Green
Jupiter Red
Sunset Red
Velvet Red
Iridium Silver
Arctic White
Grey White
Calcite Yellow
Specs
Rear Door Type: Split Swing-Out
Engine Order Code: M5N
Engine Type: Intercooled Turbo Diesel I-4
Displacement: 2.0 L/119
Fuel System: Diesel Direct Injection
SAE Net Horsepower @ RPM: 211 @ 3800
SAE Net Torque @ RPM: 332 @ 1400
Engine Oil Cooler: None
Drivetrain: All Wheel Drive
Trans Order Code: G43
Trans Type: 9
Trans Description Cont.: Automatic w/OD
Trans Description Cont. Again:
First Gear Ratio (:1): 5.53
Second Gear Ratio (:1): 3.24
Third Gear Ratio (:1): 2.25
Fourth Gear Ratio (:1): 1.64
Fifth Gear Ratio (:1): 1.21
Sixth Gear Ratio (:1): 1.00
Reverse Ratio (:1): 4.90
Trans PTO Access: No
Transfer Case Model: Electronic
Transfer Case Power Take Off: No
Seventh Gear Ratio (:1): 0.86
Eighth Gear Ratio (:1): 0.72
Fuel Economy Est-Combined (MPG): - TBD -
EPA Fuel Economy Est - City (MPG): - TBD -
EPA Fuel Economy Est - Hwy (MPG): - TBD -
Cold Cranking Amps @ 0° F (Primary): 850
Cold Cranking Amps @ 0° F (2nd): 850
Maximum Alternator Capacity (amps): 250
Base Curb Weight (lbs): 6228
Gross Axle Wt Rating - Front (lbs): 4409
Gross Axle Wt Rating - Rear (lbs): 7721
Curb Weight - Front (lbs): 2989
Curb Weight - Rear (lbs): 3239
Gross Vehicle Weight Rating Cap (lbs): 11030
Gross Combined Wt Rating (lbs): 15250
Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
Dead Weight Hitch - Max Tongue Wt. (lbs): 500
Wt Distributing Hitch - Max Trailer Wt. (lbs): 7500
Wt Distributing Hitch - Max Tongue Wt. (lbs): 750
Maximum Trailering Capacity (lbs): 7500
Suspension Type - Front: Strut
Suspension Type - Rear: Leaf
Axle Type - Front: Independent
Axle Type - Rear: Rigid Axle
Axle Ratio (:1) - Front: 4.73
Axle Ratio (:1) - Rear: 4.73
Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Brake ABS System (Second Line): 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Drum - Rear (Yes or ):
Front Tire Order Code: RM0
Rear Tire Order Code: RM0
Spare Tire Order Code:
Front Tire Size: LT215/85SR16
Rear Tire Size: LT215/85SR16
Spare Tire Size: Full-Size
Revolutions/Mile @ 45 mph - Front: 664
Revolutions/Mile @ 45 mph - Rear: 664
Front Wheel Size (in): 16 X 5.5
Rear Wheel Size (in): 16 X 5.5
Spare Wheel Size (in): Full-Size
Front Wheel Material: Steel
Rear Wheel Material: Steel
Spare Wheel Material: Steel
Steering Type: Rack-Pinion
Turning Diameter - Curb to Curb (ft): 50.2
Fuel Tank Capacity, Approx (gal): 24.5
Side Door Type: Sliding
Wheelbase (in): 170
Length, Overall (in): 290
Width, Max w/o mirrors (in): 80
Height, Overall (in): 110.6
Ground to Top of Load Floor (in): 29.8
Ground Clearance, Front (in): 8
Ground Clearance, Rear (in): 8
Cargo Area Length @ Floor to Seat 1 (in): 189.4
Cargo Area Width @ Beltline (in): 70.4
Cargo Box Width @ Wheelhousings (in): 38.5
Cargo Box (Area) Height (in): 79.1
Cargo Volume (ft³): 469.4
Passenger Capacity: 2
Front Head Room (in): 56.4
Front Leg Room (in): 38.9
Front Shoulder Room (in): 67.4
Front Hip Room (in): 63.7
Vehicle Name: Mercedes-Benz Sprinter Cargo Van
Body Style: Extended Cargo Van 170" WB AWD
Body Code: V
Tons/yr of CO2 Emissions @ 15K mi/year: - TBD -
Pricing
This model has 24 different trims.
MSRP
$74,200
Invoice
$69,006
Description
2.0 L/119, 211 @ 3800, Automatic w/OD
Fuel Economy
This model has 24 different trims.
City
undefined MPG
Hwy
undefined MPG
Combined
undefined MPG
Description
2.0 L/119, 211 @ 3800, Automatic w/OD
