2025 Kia Carnival Hybrid
$40,800 - $52,900Starting MSRP
Aurora Black Pearl
Model Highlights
Fuel Economy
33 MPG Comb.
Transmission
Automatic w/OD
Body Type
Minivan
Seatings
8 Seats
Overview
The front-wheel-drive Carnival aims to be best again in the minivan segment. The minivan features a wide stance and cab-forward look, with a front end that integrates the Kia corporate grille.
A direct injected 3.5L V6 powers the Carnival....
Build Your Own 2025 Kia Carnival Hybrid
What’s new in the 2025 model?
The Kia Carnival gets a refreshed exterior and a hybrid model for 2025.
Looking for alternatives to the Kia Carnival Hybrid?
Start Comparing NowColors
Exterior
Aurora Black Pearl
Astra Blue
Panthera Metal
Ceramic Silver
Ivory Silver
Snow White Pearl
Specs
EPA Classification: Minivans 2WD
Gross Traction Battery Capacity (kWh): 1.5
Engine Order Code:
Engine Type: Intercooled Turbo Gas/Electric I-4
Displacement: 1.6 L/98
Fuel System: Gasoline Direct Injection
SAE Net Horsepower @ RPM: 242 @ 5500
SAE Net Torque @ RPM: 270
Drivetrain: Front Wheel Drive
Trans Order Code:
Trans Type: 6
Trans Description Cont.: Automatic w/OD
Trans Description Cont. Again:
First Gear Ratio (:1): 4.64
Second Gear Ratio (:1): 2.83
Third Gear Ratio (:1): 1.84
Fourth Gear Ratio (:1): 1.39
Fifth Gear Ratio (:1): 1.00
Sixth Gear Ratio (:1): 0.77
Reverse Ratio (:1): 3.38
Final Drive Axle Ratio (:1): 3.65
Fuel Economy Est-Combined (MPG): 33
EPA Fuel Economy Est - City (MPG): 34
EPA Fuel Economy Est - Hwy (MPG): 31
Cold Cranking Amps @ 0° F (Primary): 850
Base Curb Weight (lbs): 4581
Dead Weight Hitch - Max Trailer Wt. (lbs): 3500
Dead Weight Hitch - Max Tongue Wt. (lbs): 350
Wt Distributing Hitch - Max Trailer Wt. (lbs): 3500
Wt Distributing Hitch - Max Tongue Wt. (lbs): 350
Suspension Type - Front: Strut
Suspension Type - Rear: Multi-Link
Suspension Type - Front (Cont.): Strut
Suspension Type - Rear (Cont.): Multi-Link
Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 12.8
Rear Brake Rotor Diam x Thickness (in): 12.8
Drum - Rear (Yes or ):
Rear Drum Diam x Width (in):
Front Tire Order Code:
Rear Tire Order Code:
Spare Tire Order Code:
Front Tire Size: P235/55TR19
Rear Tire Size: P235/55TR19
Spare Tire Size:
Front Wheel Size (in): 19 X 7.5
Rear Wheel Size (in): 19 X 7.5
Spare Wheel Size (in):
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material:
Steering Type: Rack-Pinion
Turning Diameter - Curb to Curb (ft): 37.7
Fuel Tank Capacity, Approx (gal): 19
Wheelbase (in): 121.7
Length, Overall (in): 203
Width, Max w/o mirrors (in): 78.5
Height, Overall (in): 69.9
Track Width, Front (in): 68.5
Track Width, Rear (in): 68.5
Min Ground Clearance (in): 6.8
Cargo Volume to Seat 1 (ft³): 145.1
Cargo Volume to Seat 2 (ft³): 86.9
Cargo Volume to Seat 3 (ft³): 40.2
Passenger Capacity: 8
Passenger Volume (ft³): 168.2
Front Head Room (in): 39.7
Front Leg Room (in): 41.1
Front Shoulder Room (in): 64.2
Front Hip Room (in): 59.8
Second Head Room (in): 37.6
Second Leg Room (in): 40.5
Second Shoulder Room (in): 63.2
Second Hip Room (in): 66.4
Third Head Room (in): 36.5
Third Leg Room (in): 35.6
Third Shoulder Room (in): 59.5
Third Hip Room (in): 50.4
Vehicle Name: Kia Carnival Hybrid
Body Style: Passenger Van
EPA Greenhouse Gas Score: 6.0
Tons/yr of CO2 Emissions @ 15K mi/year: 5.3
Pricing
This model has 4 different trims.
MSRP
$52,900
Invoice
$51,314
Description
1.6 L/98, 242 @ 5500, Automatic w/OD
Fuel Economy
This model has 4 different trims.
City
34 MPG
Hwy
31 MPG
Combined
33 MPG
Description
1.6 L/98, 242 @ 5500, Automatic w/OD
