2025 Ford Super Duty F-350 SRW
$46,595 - $79,365Starting MSRP
Agate Black Metallic
Model Highlights
Transmission
Automatic w/OD
Body Type
Truck
Seatings
5 Seats
Build Your Own 2025 Ford Super Duty F-350 SRW
Looking for alternatives to the Ford Super Duty F-350 SRW?
Start Comparing NowColors
Exterior
Agate Black Metallic
Antimatter Blue Metallic
Darkened Bronze Metallic
Avalanche
Carbonized Gray Metallic
Glacier Gray Metallic Tri-Coat
Ruby Red Metallic Tinted Clearcoat
Star White Metallic Tri-Coat
Specs
Engine Order Code: 99N
Engine Type: Regular Unleaded V-8
Displacement: 7.3 L/445
Fuel System: Sequential MPI
SAE Net Horsepower @ RPM: 430 @ 5500
SAE Net Torque @ RPM: 485 @ 4000
Engine Oil Cooler: None
Drivetrain: Four Wheel Drive
Trans Order Code: 44G
Trans Type: 10
Trans Description Cont.: Automatic w/OD
Trans Description Cont. Again:
First Gear Ratio (:1): 4.62
Second Gear Ratio (:1): 2.92
Third Gear Ratio (:1): 2.13
Fourth Gear Ratio (:1): 1.77
Fifth Gear Ratio (:1): 1.52
Sixth Gear Ratio (:1): 1.28
Reverse Ratio (:1): 4.70
Trans Power Take Off:
Trans PTO Access: No
Transfer Case Model: Electronic
Transfer Case Power Take Off: No
Seventh Gear Ratio (:1): 1.00
Eighth Gear Ratio (:1): 0.85
Cold Cranking Amps @ 0° F (Primary): 750
Cold Cranking Amps @ 0° F (2nd): 750
Maximum Alternator Capacity (amps): 250 & 160
Base Curb Weight (lbs): 6999
Gross Axle Wt Rating - Front (lbs): 5600
Gross Axle Wt Rating - Rear (lbs): 7230
Curb Weight - Front (lbs): 4119
Curb Weight - Rear (lbs): 2880
Gross Vehicle Weight Rating Cap (lbs): 11900
Gross Combined Wt Rating (lbs): 25200
Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
Dead Weight Hitch - Max Tongue Wt. (lbs): 500
Wt Distributing Hitch - Max Trailer Wt. (lbs): 17800
Wt Distributing Hitch - Max Tongue Wt. (lbs): 1780
Fifth Wheel Hitch - Max Trailer Wt. (lbs): 17600
Fifth Wheel Hitch - Max Tongue Wt. (lbs): 4400
Maximum Trailering Capacity (lbs): 17800
Suspension Type - Front: Other
Suspension Type - Rear: Leaf
Spring Capacity - Front (lbs): 5600
Spring Capacity - Rear (lbs): 7230
Axle Type - Front: Non-Independent
Axle Type - Rear: Rigid Axle
Axle Capacity - Front (lbs): 6000
Axle Capacity - Rear (lbs): 7280
Axle Ratio (:1) - Front: 3.73
Axle Ratio (:1) - Rear: 3.73
Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Brake ABS System (Second Line): 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 14.3
Rear Brake Rotor Diam x Thickness (in): 14.3
Drum - Rear (Yes or ):
Rear Drum Diam x Width (in):
Front Tire Order Code: TCW
Rear Tire Order Code: TCW
Spare Tire Order Code:
Front Tire Size: LT275/65SR20
Rear Tire Size: LT275/65SR20
Spare Tire Size: Full-Size
Front Tire Capacity (lbs): 7180
Rear Tire Capacity (lbs): 7180
Revolutions/Mile @ 45 mph - Front: 612
Revolutions/Mile @ 45 mph - Rear: 612
Front Wheel Size (in): 20 X 8
Rear Wheel Size (in): 20 X 8
Spare Wheel Size (in): Full-Size
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material: Steel
Steering Type: Re-Circulating Ball
Turning Diameter - Curb to Curb (ft): 57.8
Fuel Tank Capacity, Approx (gal): 48
Wheelbase (in): 176
Length, Overall (in): 266.2
Width, Max w/o mirrors (in): 80
Height, Overall (in): 81.1
Overhang, Front (in): 38.2
Cab to Axle (in): 56.1
Ground to Top of Load Floor (in): 36.5
Ground Clearance, Front (in): 8.5
Ground Clearance, Rear (in): 8.5
Cargo Box Length @ Floor (in): 98.1
Cargo Box Width @ Top, Rear (in): 66.9
Cargo Box Width @ Floor (in): 66.9
Cargo Box Width @ Wheelhousings (in): 50.5
Cargo Box (Area) Height (in): 21.1
Tailgate Width (in): 60.5
Cargo Volume (ft³): 78.5
Passenger Capacity: 5
Front Head Room (in): 40.8
Front Leg Room (in): 43.9
Front Shoulder Room (in): 66.7
Front Hip Room (in): 62.5
Second Head Room (in): 40.4
Second Leg Room (in): 43.6
Second Shoulder Room (in): 65.9
Second Hip Room (in): 64.7
Vehicle Name: Ford Super Duty F-350 SRW
Body Style: SD Crew Cab
Body Code: T
Pricing
This model has 18 different trims.
MSRP
$79,365
Invoice
$75,396
Description
7.3 L/445, 430 @ 5500, Automatic w/OD
Fuel Economy
This model has 18 different trims.
City
undefined MPG
Hwy
undefined MPG
Combined
undefined MPG
Description
7.3 L/445, 430 @ 5500, Automatic w/OD
