2023 Ford Ranger
$27,400 - $40,945Starting MSRP
Shadow Black
Model Highlights
Fuel Economy
22 MPG Comb.
Transmission
Automatic w/OD
Body Type
Truck
Seatings
5 Seats
Overview
The 4-cylinder engine powering all Rangers displaces 2.3 liters and makes 270 horsepower and 310 lb.-ft of torque, which is sent to the rear wheels via a 10-speed automatic transmission, the only transmission available on the Ford Ranger. Buyers...
What’s new in the 2023 model?
The 2023 Ford Ranger carries over with minimal changes.
Looking for alternatives to the Ford Ranger?
Start Comparing NowColors
Exterior
Shadow Black
Velocity Blue Metallic
Azure Gray Metallic Tri-Coat
Cactus Gray
Carbonized Gray Metallic
Eruption Green Metallic
Hot Pepper Red Metallic Tinted Clearcoat
Race Red
Iconic Silver Metallic
Oxford White
Specs
Engine Order Code: 99H
Engine Type: Intercooled Turbo Regular Unleaded I-4
Displacement: 2.3 L/140
Fuel System: Gasoline Direct Injection
SAE Net Horsepower @ RPM: 270 @ 5500
SAE Net Torque @ RPM: 310 @ 3000
Engine Oil Cooler: None
Drivetrain: Four Wheel Drive
Trans Order Code: 44U
Trans Type: 10
Trans Description Cont.: Automatic w/OD
Trans Description Cont. Again:
First Gear Ratio (:1): 4.70
Second Gear Ratio (:1): 2.98
Third Gear Ratio (:1): 2.15
Fourth Gear Ratio (:1): 1.77
Fifth Gear Ratio (:1): 1.52
Sixth Gear Ratio (:1): 1.27
Reverse Ratio (:1): 4.87
Trans PTO Access: No
Transfer Case Model: Electronic
Transfer Case Power Take Off: No
Seventh Gear Ratio (:1): 1.00
Eighth Gear Ratio (:1): 0.85
Fuel Economy Est-Combined (MPG): 22
EPA Fuel Economy Est - City (MPG): 20
EPA Fuel Economy Est - Hwy (MPG): 24
Cold Cranking Amps @ 0° F (Primary): 800
Cold Cranking Amps @ 0° F (2nd): 800
Maximum Alternator Capacity (amps): 150
Base Curb Weight (lbs): 4441
Gross Axle Wt Rating - Front (lbs): 3130
Gross Axle Wt Rating - Rear (lbs): 3370
Curb Weight - Front (lbs): 2554
Curb Weight - Rear (lbs): 1887
Gross Vehicle Weight Rating Cap (lbs): 6050
Gross Combined Wt Rating (lbs):
Dead Weight Hitch - Max Trailer Wt. (lbs):
Dead Weight Hitch - Max Tongue Wt. (lbs):
Wt Distributing Hitch - Max Trailer Wt. (lbs):
Wt Distributing Hitch - Max Tongue Wt. (lbs):
Maximum Trailering Capacity (lbs):
Suspension Type - Front: Short And Long Arm
Suspension Type - Rear: Leaf
Spring Capacity - Front (lbs): 3130
Spring Capacity - Rear (lbs): 3370
Axle Type - Front: Independent
Axle Type - Rear: Rigid Axle
Axle Capacity - Front (lbs): 3130
Axle Capacity - Rear (lbs): 3370
Axle Ratio (:1) - Front: 3.73
Axle Ratio (:1) - Rear: 3.73
Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Brake ABS System (Second Line): 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 12.2
Rear Brake Rotor Diam x Thickness (in): 12.1
Drum - Rear (Yes or ):
Rear Drum Diam x Width (in):
Front Tire Order Code:
Rear Tire Order Code:
Spare Tire Order Code:
Front Tire Size: P265/60SR18
Rear Tire Size: P265/60SR18
Spare Tire Size: Full-Size
Front Tire Capacity (lbs): 3263
Rear Tire Capacity (lbs): 4079
Front Wheel Size (in): 18 X 8
Rear Wheel Size (in): 18 X 8
Spare Wheel Size (in): Full-Size
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material: Steel
Steering Type: Rack-Pinion
Turning Diameter - Curb to Curb (ft): 42
Fuel Tank Capacity, Approx (gal): 18
Wheelbase (in): 126.8
Length, Overall (in): 210.8
Width, Max w/o mirrors (in): 77.8
Height, Overall (in): 71.5
Overhang, Front (in): 35.8
Ground to Top of Load Floor (in): 33.8
Ground Clearance, Front (in): 8.9
Ground Clearance, Rear (in): 8.9
Cargo Box Length @ Floor (in): 61
Cargo Box Width @ Top, Rear (in): 61.4
Cargo Box Width @ Floor (in): 61.4
Cargo Box Width @ Wheelhousings (in): 44.8
Cargo Box (Area) Height (in): 20.9
Tailgate Width (in): 55.4
Cargo Volume (ft³): 43.3
Passenger Capacity: 5
Front Head Room (in): 39.8
Front Leg Room (in): 43.1
Front Shoulder Room (in): 56.7
Front Hip Room (in): 55.8
Second Head Room (in): 38.3
Second Leg Room (in): 34.5
Second Shoulder Room (in): 56.3
Second Hip Room (in): 53.5
Vehicle Name: Ford Ranger
Body Style: SuperCrew
Body Code: T
Tons/yr of CO2 Emissions @ 15K mi/year: 8.1
Pricing
This model has 12 different trims.
MSRP
$40,945
Invoice
$39,307
Description
2.3 L/140, 270 @ 5500, Automatic w/OD
Fuel Economy
This model has 12 different trims.
City
20 MPG
Hwy
24 MPG
Combined
22 MPG
Description
2.3 L/140, 270 @ 5500, Automatic w/OD
